Wiring
|
Notch
|
Turnover
|
|
Input:
|
|
A B C D E F G H I J K L M N O P Q R
S T U V W X Y Z
|
|
|
|
|
I
|
E K M F L G D Q V Z N T O W Y H X U
S P A I B R C J
|
Y
|
Q
|
|
|
II
|
A J D K S I R U X B L H W T M C Q G
Z N P Y F V O E
|
M
|
E
|
|
|
III
|
B D F H J L C P R T X V Z N Y E I W
G A K M U S Q O
|
D
|
V
|
|
|
IV
|
E S O V P Z J A Y Q U I R H X L N F
T G K D C M W B
|
R
|
J
|
|
|
V
|
V Z B R G I T Y U P S D N H L X A W
M J Q O F E C K
|
H
|
Z
|
|
|
VI
|
J P G V O U M F Y Q B E N H Z R D K
A S X L I C T W
|
H,U
|
Z,M
|
| |
VII
|
N Z J H G R C X M Y S
W B O U F A I V L P E K Q D T |
H,U
|
Z,M
|
|
|
VIII
|
F K Q H T L X O C B J S P D Z R A M
E W N I U Y G V
|
H,U
|
Z,M
|
|
'Greek'
|
|
'Walzen' |
|
|
|
Beta
|
|
L E Y J V C N I X W P B Q M D R T A
K Z G F U H O S
|
none
|
M-4 only
|
|
Gamma
|
|
F S O K A N U E R H M B T I Y C W L
Q P Z X V G J D
|
none
|
M-4 only
|
| |
|
|
|
|
|
UKW
|
|
'Umkehrwalze' |
|
|
|
|
B
|
Y R U H Q S L D P X N G O K M I E B
F Z C W V J A T
|
none
|
|
|
|
C
|
F V P J I A O Y E D R Z X W G C T K
U Q S B N M H L
|
none
|
|
| |
|
|
|
|
|
`Thin'
|
B
|
E N K Q A U Y W J I C
O P B L M D X Z V F T H R G S |
none
|
M4 only
|
|
`Thin'
|
C
|
R D O B J N T K V E H
M L F C W Z A X G Y I P S U Q |
none
|
M4 only
|
|
|
|
Use 'Thin' UKW with 'Greek'
wheels |
|
|
| |
|
Notes |
|
|
|
Notch:
|
|
The location of
advance notch on the index ring. |
|
|
|
Turnover:
|
|
The letter appearing
in window as the advance notch is engaged with the stepping lever.
|
|
|
| |
|
Wheels Beta and Gamma
have index rings but do not have notches. |
|
|
|
|
|
'Thin' reflectors B
and C are used only in the Model M-4 with Beta and Gamma wheels. |
|
